Chassis car dyno
We produce best chassis dynamometers for cars. Please choose one of the car chassis dynamometer and make enquiry.
Chassis car dyno machines
Comparison
| Feature | 1500brd 2WD BRAKED | 1500i 2WD INERTIAL | 4000brd 4WD BRAKED | 4000BRD PRO 4WD BRAKED | 5000BRD 4WD BRAKED | 5000BRD PRO 4WD BRAKED |
|---|---|---|---|---|---|---|
| Model / type | 2WD, Braked | 2WD, Inertial | 4WD, Braked, Synchronized | 4WD, Braked, Synchronized | 4WD, Braked, Synchronized | 4WD, Braked, Synchronized |
| Dimensions (L x W) | 1200 x 3600 mm | 1200 x 3600 mm | 4000 x 3600 mm | 4000 x 3600 mm | 4000 x 3600 mm | 4000 x 3600 mm |
| Wheelbase min/max | 2200/900 mm | 2200/900 mm | 3300/2250 mm | 3300/2250 mm | 3300/2250 mm | 3300/2250 mm |
| Min/Max Track | 2200/900mm | 2200/900mm | 2200/900mm | 2200/900mm | ||
| Roll Diameter | 350 mm | 350 mm | 270 mm | 325 mm | 325 mm | 325 mm |
| Weight on Axle | 3000 kg | 3000 kg | up to 3000 kg | up to 3000 kg | up to 3000 kg | up to 3000 kg |
| Axles | х 2 | х 2 | х 5 | х 5 | х 5 | х 5 |
| Electromagnetic Brake | 2000N x 1 | 2000N x 1 | 2000N x 2 | 2000N x 1 | 2000N x 2 | |
| Vmax | 300 kph | 300 kph | 300 kph | 300 kph | 300 kph | 300 kph |
| Modes of Operation | inertial | inertial | inertial | inertial | inertial | inertial |
| loaded | loaded | loaded | loaded | loaded | ||
| road conditions | road conditions | road conditions | road conditions | road conditions | ||
| constant speed | constant speed | constant speed | constant speed | constant speed | ||
| Pmax Inertial Mod | 650 hp | 650 hp | 1250 hp | 1250 hp | 1500 hp | 1500 hp |
| Pmax Constant Speed and Road Conditions | 1250 hp | 1350 hp | 1700 hp | 1250 hp | 1800 hp | |
| Pmax Dynamic Mode from the Wheels | 1100 hp | 1100 hp | 2000 hp | 1700 hp | 2000 hp | |
| Accuracy Inertial Mode | 0,10% | 0,10% | 0,10% | 0,10% | 0,10% | 0,10% |
| Accuracy Loaded Mode | 1% | 1% | 1% | 1% | 2% | 2% |
| Voltage min AC | 220V / 16A | 220V / 16A | 220V / 40A | 220V / 40A | 220V / 40A | 220V / 40A |
| Air Pressure | min 5 bar | min 6 bar | min 5 bar | min 5 bar | min 5 bar | min 5 bar |
| Extras | Wide Band Lambda | Wide Band Lambda | Wide Band Lambda | Wide Band Lambda | Wide Band Lambda | Wide Band Lambda |
| OBD, Wifi Weather Station | OBD, Wifi Weather Station | OBD, Wifi Weather Station | OBD, Wifi Weather Station | OBD, Wifi Weather Station | OBD, Wifi Weather Station | |
| DynomiZer Wireless Software | DynomiZer Wireless Software | DynomiZer Wireless Software | DynomiZer Wireless Software | DynomiZer Wireless Software | DynomiZer Wireless Software | |
| Basic composition | in-pit / surface-mounted | in-pit / surface-mounted | in-pit / surface-mounted | in-pit / surface-mounted | in-pit / surface-mounted | in-pit / surface-mounted |
