DYNOMAX MOTORCYCLE DYNO

ELECTROMAGNETIC RETARDER
measuring up to 900hp

Enquiry

Details

Feature Value
Model / type 4WD, Braked, Synchronized
Dimensions (L x W) 4000 x 3600 mm
Wheelbase min/max 3300/2250 mm
Min/Max Track 2200/900mm
Roll Diameter 325 mm
Weight per Axle up to 3000 kg
Axles х 5
Electromagnetic Brake 2000N x 2
Max Test Speed 300 kph
Modes of Operation
  • inertial
  • loaded
  • road conditions
  • constant speed
Pmax Inertial Mod 1500 hp
Pmax Constant Speed and Road Conditions 1800 hp
Pmax Dynamic Mode from the Wheels 2000 hp
Accuracy Inertial Mode 0,1%
Accuracy Loaded Mode 2%
Voltage min AC 220V / 40A
Air Pressure min 5 bar
Extras
  • Wide Band Lambda
  • OBD, Wifi Weather Station
  • DynomiZer Wireless Software
Basic composition in-pit / surface-mounted
